PressIT360 is the all-in-one web conferencing system with high-performance 360-degree camera, mic and speakers, supporting a hybrid working environment that connects online with offline.
| TY-CSP1 | |
|---|---|
| Camera | Viewing angle: 360 degrees |
| Field of view | 360 (H) x 60 (V) |
| Microphone | 7 |
| Speaker | 1.5 W(When supplying power from USB Type-C) or 3 W(When AC adaptor is connected) |
| Dimensions | Φ64 mm × 285 mm/Φ2.52" x 11.23“ (Operation base Φ100 mm (Φ3.94")) |
Related video
Connect the cable to the PC and start the meeting immediately
Simply connect the camera, microphone, and speakers in one unit to a computer with a USB Type-C (hereafter referred to as USB-C) cable. No time is needed to prepare and set up equipment, so meetings can be started smoothly.
1. Bring into the conference room
2. Just connect to a PC using USB-C
3. Start web conference
Only one USB-C is needed to connect to a PC.
Video and audio data can be sent to your PC with a single USB-C. Since the terminal integrates a camera, microphone, and speakers, there is no need to prepare separate equipment.1
1：For connection to a USB-C port of a PC capable of supplying 5V/3A of power. It can also be connected using an AC adapter. When using the USB-C to USB-C alone, volume is limited compared to when using the AC adapter.
Easy operation with just the push of a button
Volume control, muting, and video mode selection can be intuitively operated using buttons on the control panel of the main unit. The LED ring also informs the user of the operating status by color. You can check whether the microphone is on or off, etc., at a glance.
Clear video and audio transmission for natural and realistic communication
Common issues that occur in web conferencing, such as not knowing who is speaking, waiting for someone to speak, and howling can be eliminated.
Four cameras capture 360-degree horizontal images, so when placed in the center of a conference room, participants at any seat can be seen in high quality and realistic images. The microphone also cover a wide 360-degree horizontal area and can recognize voices from a radius of up to five meters. The system also features echo and noise cancellation and volume equalization, which automatically adjusts to make it easier to hear participants, eliminating the sound trouble that can be a challenge in web conferencing. The system supports natural communication with people participating in a conference at a distance by collecting and amplifying clear sound.
The original performance may not be achieved depending on the conference system used, Internet connection speed, and bandwidth.
A variety of video modes to choose from according to the situation
It is possible to focus on the speaker or to display a fixed whiteboard
Five different video modes allow meetings to proceed with the camera layout best suited for communication. For example, by using Multi view, a green bar indicating the speaker is lit on the PC on the remote worker, making it easy to recognize the speaker. Remote work participants will be able to read the expressions on the office side of the room and know when to speak up.
Dual view
360-degrees view the conference room.
Focuses on up to two speakers.
Single view
Focus on the person speaking in the conference room.
Multi view
Focuses on up to four speakers. Shows a green bar above the speaker screen.
Surround view
360-degree overall display divided to two 180-degree screens.
Stable view
Displays images with a fixed position as a web camera.
The green LED gradation changes in the direction of the speaker's voice.
This function may not be activated in certain modes
Focus on the person speaking is automatically optimized according to the volume of speech and the length of the utterance. Focus may be delayed or not performed depending on the situation.
Expand usage scenarios with ease of installation
Functional size and sophisticated design
Diameter 64 mm(2.52"), height 285 mm(11.23"), weight approx. 950 g(2.1 lbs.).
The slim shape and seamless fabric netting create a discreet appearance that is unobtrusive even when placed in the center of a conference table. The camera captures the participants' faces at an optimal angle of incidence without overlapping with the computer, so you can concentrate on the discussion without worrying about the equipment.
Laptop for business
- Windows: Lenovo (Thinkpad L15 15.6 inch), HP(250 G8 15.6 inch), Dell (Vostro 15.6 inch),
- Mac: MacBook Pro (max size 16 inch)
Equipped with a 1/4-inch tripod fixing screw hole
The bottom of the unit is equipped with a 1/4-inch screw hole, so it can be fixed to a tripod and permanently installed in a location other than on a desk. It is also equipped with a Noble Wedge lock security slot1, which can be connected to a security wire to protect valuable equipment from being stolen in case of theft.
1: Mounting surface Φ11 mm or less.
Fine settings can be made on the PC, including picture quality adjustment and setting changes.
The PressIT360App built into the unit can be installed on a PC to perform detailed settings.
- Display of camera images
- Image quality adjustment
- Speaker operation test
- Firmware update and version confirmation
- Video control1 (zoom in/zoom out, tilt up/down, pan left/right) *May not work on some models.
1: Adjustment of the camera images and the zoom in and zoom out features work only on the camera image screen of this application.
Supporting operation systems for the PC app are Microsoft Windows (Windows 10/11), and macOS.
PressIT360 can be used with various web conferencing systems
It can be used with web conferencing systems such as Microsoft Teams, Zoom, Cisco Webex®, and Google Meet™.
* This does not guarantee operation on the web conferencing system.
* Microsoft and Microsoft Teams are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. ZOOM is a trademark of Zoom Video Communications, Inc. Cisco Webex is trademarks and/or registered trademarks of Cisco and/or its affiliates. Google Meet is trademark or registered trademark of Google LLC.
360° camera speakerphone optimized for the web conferencing system "Microsoft Teams"
PressIT360 is certified for "Microsoft Teams," a collaboration platform offered by Microsoft Corporation.
The optimal image and sound quality that naturally conveys the atmosphere of the conference room will elevate communication during web conferencing.
* Surround view and Stable view is not recommended for Microsoft Teams Rooms.
* Microsoft and Microsoft Teams are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries
