Wireless Presentation System

WPS2 Series

* The availability varies depending on the country.

Simply connect the transmitter and display 4K images on the screen with the push of a button.

Wireless Presentation System

Model number TY-WPS2 (Basic set) TY-WPSC2 (Basic set) TY-WPB2 TY-WPBC2 TY-WPR2
Product details Receiver x 1
Transmitter (HDMI™/USB-A) x 2
Transmitter Case x 1
Receiver x 1
Transmitter (USB-C) x 2
Transmitter Case x 1
Transmitter
(HDMI™/USB-A) x 1
Transmitter
(USB-C) x 1
Receiver x 1

Main Features

No software installation required. Easily share screens with the push of a button.
Compatible with 6GHz band wireless LAN. The number of connection channels has increased, improving the installation flexibility.
Wireless communication that combines security and ease of use.

No drivers or software required. Easily share screens with the push of a button

PressIT does not require any special drivers or software to be installed. Simply connect the transmitter to your PC and press the button to display images on the display. You can also share your screen from mobile devices such as smartphones and tablets. With the WPS2 series, it is now possible to transmit 4K video, and display high-definition images and text. The transmitter has inherited the round shape that fits comfortably in your hand, and a design that makes it easy to press the buttons has been adopted. The transmission and reception status and mode settings can be checked by the color of the LED light.

Simple operation with the plug-and-play presentation system

Compatible with mobile devices [Android™ devices, iOS/iPadOS devices]

By installing the dedicated “PressIT” app from Google Play/App Store, you can mirror (project) the image on your device onto a display or projector.

Click here to download the app

Flexible installation to suit your space

Transmit 4K images NEW

4K (up to 3840/30p) playback is possible for both video and still images. High-definition text and images can also be displayed wirelessly.

Make your Teams meetings even more comfortable by connecting in-person and remote participants NEW

When the presenter presses the main button, the PC screen is sent to the display in the meeting room and also displayed on the Teams screen. The screen is also shared with remote participants, making it easier to hold hybrid meetings.

* A Teams Rooms terminal must be prepared separately and pre-configured.

Flexible installation to suit your space

Supports HDMI-CEC

The system can be operated by linking the power on/off and input switching of the display and projector, so there is no need for remote control operation.

* An HDMI-CEC compatible display or projector is required. This does not guarantee control of all devices.

The installation flexibility has improved, making it possible to run meetings and seminars more efficiently

PressIT is compatible with 6GHz band wireless LAN. Since 24 channels can be used, even if multiple receivers are installed on the same floor, it is difficult for them to interfere with each other, leading to greater installation flexibility1. Up to 32 transmitters can be connected simultaneously to one receiver. This saves the trouble of moving seats and passing cables each time a presenter changes. In addition, the system supports multicasting, which allows a single transmitter to share video and audio with multiple receivers. There is no longer a need for a router, which was required with the previous model,2 and content can be streamed from the presenter to multiple displays, allowing meetings and seminars to be run efficiently.

1: Depending on the environment in which it is used, this product may be affected by radio waves other than its own. It does not eliminate the effects of all radio wave interference.

2: The system can also be connected using a commercially available router.

Flexible installation to suit your space

Up to 32 devices can be connected simultaneously

Up to 32 transmitters can be connected simultaneously to a single receiver, making it ideal for training large groups.

Supports Multicast function

Share video and audio from a single transmitter to multiple receivers (up to three units) without using a router.

Flexible installation to suit your space

Multi Mode (supports four-screen display)

Display split-screen images from up to four PCs or smartphones on a single display. This allows you to efficiently compare documents and share ideas, making discussions and meetings run more smoothly.
Press and hold the sub button while the screen is being projected.

Flexible installation to suit your space

Lock Mode

Press the main button for several seconds to activate lock mode. Prevents screen interruption during lectures and presentations.

Flexible installation to suit your space

Reliable wireless transmission for effortless use

The connection to the transmitter's USB port is exclusively for power supply and is not recognized as an external device/storage/media, so guests using computers with high security standards can also use it with peace of mind. Communication between paired transmitters and receivers is encrypted, allowing you to send data safely.

Safe performance that can be used even on PCs with strict security settings

The security level is maintained even with a wireless connection, reducing the risk of information leaks and virus infections.

  • WPA2/WPA3 standard compliant
  • Supports the IEEE802.11ac 6GHz (maximum 2.4Gbps) wireless standard

Design focused on ease of use

The round shape fits comfortably in your hand, and the concave design makes it easy to find and press the buttons intuitively.
The transmitter has a built-in magnet, so it can be attached to steel fixtures for storage.

Flexible installation to suit your space

Choose from two types of receiver to suit your installation environment

You can choose from two types of receivers. The board-type fits into the slot of the display or projector itself.
The box-type is also compact, and has a discreet design that can be attached to a desktop or ceiling-mounted projector.

IPS

[Set top box]
Compatible with USB power supply (5V / 2A)
Power can be supplied from the display/projector.

IPS

[Function board]
Compatible with displays and projectors with our Intel® SDM specification slots.
(Communication will use only the 5GHz band wireless LAN.)

See the list of compatible display/projector models.
