Panasonic offers a wide selection of optional fixed and zoom lenses for compatible projectors. To find the perfect lens for your planned application, complete with throw-distance estimates and details on individual lens models, click a Category tab below and select a lens compatible with your projector. To discover how our optional ultra-short-throw and short-throw lenses can revitalize your space, click the Key Features tab above.
For PT-RQ50K Projector
Throw Ratio Table
-
600-inch
-
300-inch
Quick Reference Guide
| Compatible Projector |
Model Number | Product Image | F Number | Focal Distance [inch] |
Throw Ratio |
|---|---|---|---|---|---|
| RQ50K | ET-D3QW200 |
|
2.5 | 17.5-20.7 mm [11/16" - 13/16"] |
Zoom Native 4K 0.548-0.650:1 |
| ET-D3QW300 |
|
2.5 | 35.2-53.7 mm [1-3/8" - 2-1/8"] |
Zoom Native 4K 1.11-1.70:1 |
|
| ET-D3QS400 |
|
2.5 | 45.3-65.6 mm [1-25/32" - 2-19/32"] |
Zoom Native 4K 1.43-2.09:1 |
|
| ET-D3QT500 |
|
2.5 | 61.4-105.2 mm [2-13/32" - 4-1/8"] |
Zoom Native 4K 2.00-3.41:1 |
|
| ET-D3QT600 |
|
2.5 | 85.0-121.6 mm [3-11/32" - 4- 25/32"] |
Zoom Native 4K 2.69-3.88:1 |
|
| ET-D3QT700 |
|
2.5 | 122.8-172.3 mm [4-27/32" - 6-25/32"] |
Zoom Native 4K 3.89-5.47:1 |
|
| ET-D3QT800 |
|
2.5 | 156.5-243.1 mm [6-5/32" - 9-9/16"] |
Zoom Native 4K 4.97-7.76:1 |
For 3-Chip DLP™ Projectors
- Compatible Projectors:
- PT-RQ35K/RZ34K/RZ31K/RZ21K/RZ16K
Throw Ratio Table
-
300-inch
-
200-inch
- Compatible Projectors:
- PT-RQ32K/RQ22K
Throw Ratio Table
-
300-inch
- Compatible Projectors:
- PT-RQ25K/RZ24K/RZ18K/RZ17K/RZ14K
Throw Ratio Table
-
300-inch
- Compatible Projectors:
- PT-RQ13K, PT-RZ12K, PT-RS11K
Throw Ratio Table
-
300-inch
-
200-inch
Quick Reference Guide
| Compatible Projector |
Model Number | Product Image | F Number | Focal Distance [inch] |
Throw Ratio |
|---|---|---|---|---|---|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K RQ13K RZ12K RS11K |
ET-D75LE95 |
|
2.5 | 7.5 mm [9/32"] |
Fixed
|
| ET-D3LEU100 ET-D3LEU101 |
|
2.5 | 8.0 mm [5/16"] |
Fixed
|
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K |
ET-D3LEW200 ET-D3LEW201 |
|
2.5 | 13.8-18.1 mm [17/32" - 23/32"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K RQ13K RZ12K RS11K |
ET-D3LEW50 |
|
2.5 | 14.8 mm [19/32"] |
Fixed
|
|
RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K RQ13K RZ12K RS11K |
ET-D75LE50 |
|
2.5 | 14.8 mm [19/32"] |
Fixed
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K |
ET-D3LEW300 It may not be usable depending on the main firmware version. Please update to the latest firmware before use. Please refer to the instruction manual for details. |
|
2.5 | 16.36-19.63 mm [41/64" - 49/64"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K |
ET-D3LEW60 |
|
2.5 | 19.63-23.54 mm [17/32" - 23/32"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K RQ13K RZ12K RS11K |
ET-D75LE6 |
|
2.5 | 19.63-23.54 mm [17/32" - 23/32"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K |
ET-D3LEW10 |
|
2.5 | 26.6-36.4 mm [1-1/16" - 1-7/16"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K RQ13K RZ12K RS11K |
ET-D75LE10 |
|
2.5 | 27.4-35.4 mm [1-3/32" - 1-3/8"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K |
ET-D3LES20 |
|
2.5 | 35.0-50.9 mm [1-3/8" - 2"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K RQ13K RZ12K RS11K |
ET-D75LE20 |
|
2.5 | 35.0-50.9 mm [1-3/8" - 2"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K |
ET-D3LET30 |
|
2.5 | 50.4-98.0 mm [1-31/32" - 3-7/8"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K RQ13K RZ12K RS11K |
ET-D75LE30 |
|
2.5 | 50.5-97.9 mm [1-31/32" - 3-7/8"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K |
ET-D3LET40 |
|
2.5 | 96.6-154.9 mm [3-13/16" - 6-3/32"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K RQ13K RZ12K RS11K |
ET-D75LE40 |
|
2.5 | 96.6-154.1 mm [3-13/16" - 6- 1/16"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K |
ET-D3LET80 |
|
2.5-2.7 | 154-289 mm [6-1/16" - 11-3/8"] |
Zoom
|
|
RQ35K RZ34K RQ32K RZ31K RS30K RQ25K RZ24K RQ18K RZ17K RZ14K RQ22K RZ21K RS20K RZ16K RQ13K RZ12K RS11K |
ET-D75LE8 |
|
2.5-2.7 | 154-289 mm [6-1/16" - 11-3/8"] |
Zoom
|
For 1-Chip DLP™ Projectors
- Compatible Projectors:
- PT-REQ15/REQ12/REQ10/REQ80, PT-REZ15/REZ12/REZ10/REZ80
Throw Ratio Table
-
150-inch
Quick Reference Guide
| Compatible Projector |
Model Number | Product Image | F Number | Focal Distance [inch] |
Throw Ratio |
|---|---|---|---|---|---|
|
REQ15 REQ12 REQ10 REQ80 REZ15 REZ12 REZ10 REZ80 |
ET-C1U100 |
|
2.13 | 5.4 - 5.8 mm [14/64" - 15/64"] |
Zoom 0.308-0.330:1 |
| ET-C1U200 |  Note: Image is an illustration. |
2.0 |
6.4mm |
Fixed 0.380:1 (TBD) |
|
| ET-C1W300 |
|
1.94-2.28 | 9.9-12.3mm [3/6" - 15/32"] |
Zoom 0.550-0.690:1 |
|
| ET-C1W400 |
|
1.94-2.39 | 12.1-16.9 mm [15/32" - 21/32"] |
Zoom 0.680-0.950:1 |
|
| ET-C1W500 |
|
1.84-2.34 | 16.7-24.6 mm [21/32" - 31/32"] |
Zoom 0.940-1.39:1 |
|
| ET-C1S600 |
|
1.84-2.31 | 23.9-37.2 mm [30/32" - 1-15/32"] |
Zoom 1.36-2.10:1 |
|
| ET-C1T700 |
|
1.94-2.38 | 36.1-59.6 mm [1-13/32" - 2-11/32"] |
Zoom 2.07-3.38:1 |
|
| ET-C1T800 |  Note: Image is an illustration. |
1.9-2.5 |
58.3-115.6 mm |
Zoom 3.30-6.60:1 (TBD) |
- Compatible Projectors:
- PT-RCQ10/RCQ80, PT-RZ120, PT-RZ990/RZ890/RZ790/RZ690, PT-RQ7L/RQ6L/RZ7L/RZ6L
Throw Ratio Table
-
150-inch
Note: Throw-ratio value varies depending on the projector model's aspect ratio.
1 ET-DLE020G is intended for the RQ7 Series.
Quick Reference Guide
| Compatible Projector |
Model Number | Product Image | F Number | Focal Distance [inch] |
Throw Ratio |
|---|---|---|---|---|---|
| RCQ10 RCQ80 RZ120 RZ990 RZ890 RZ790 RZ690 RQ7L RQ6L RZ7L RZ6L |
ET-DLE020/ DLE020G1 |
|
2.0 | 4.1-4.4 mm [5/32" - 11/64"] |
Zoom 0.280-0.299:1 |
| ET-DLE035/ DLE030 |
|
2.0 | 5.3 mm [7/32"] |
Fixed 0.380:1 |
|
| ET-DLE055 |
|
1.8 | 11.9 mm [15/32"] |
Fixed 0.785:1 |
|
| ET-DLE060 |
|
1.85-2.34 | 9.16-12.1 mm [3/8" - 15/32"] |
Zoom 0.600-0.801:1 |
|
| ET-DLE085 |
|
1.85-2.20 | 11.8-14.6 mm [15/32" - 9/16"] |
Zoom 0.782-0.977:1 |
|
| ET-DLE105 |
|
1.85-2.35 | 14.7-19.7 mm [19/32" - 25/32"] |
Zoom 0.978-1.32:1 |
|
| ET-DLE150 |
|
1.8-2.4 | 19.4-27.9 mm [3/4" - 1-3/32"] |
Zoom 1.30-1.89:1 |
|
| ET-DLE170 |
|
1.7-1.9 | 25.6-35.7 mm [1" - 1-13/32"] |
Zoom 1.71-2.41:1 |
|
| ET-DLE250 |
|
1.8-2.4 | 33.9-53.2 mm [1-11/32" - 1-13/32"] |
Zoom 2.27-3.62:1 |
|
| ET-DLE350 |
|
1.8-2.2 | 52.8-79.5 mm [2-3/32" - 3-1/8"] |
Zoom 3.58-5.45:1 |
|
| ET-DLE450 |
|
1.8-2.4 | 79.5-125.2 mm [3-1/8" - 4-59/64"] |
Zoom 5.36-8.58:1 |
1 ET-DLE020G is intended for the RQ7 Series.
For PT-MZ20KL Projector
- Compatible Projectors:
- PT-MZ20KL
Throw Ratio Table
-
300-inch
Quick Reference Guide
| Compatible Projector |
Model Number | Product Image | F Number | Focal Distance [inch] |
Throw Ratio |
|---|---|---|---|---|---|
| MZ20KL | ET-EMU100 |
|
1.9 | 7.23-7.73 mm [9/32" - 5/16"] |
Zoom 0.330-0.353:1 |
| ET-EMW200 |
|
1.84-2.14 | 10.80-12.52 mm [7/16" - 1/2"] |
Zoom 0.480-0.550:1 |
|
| ET-EMW300 |
|
1.84-2.24 | 12.31-15.43 mm [1/2" - 19/32"] |
Zoom 0.550-0.690:1 |
|
| ET-EMW400 |
|
11.84-2.24 | 15.30-21.10 mm [19/32" - 27/32"] |
Zoom 0.690-0.950:1 |
|
| ET-EMW500 |
|
1.80-2.35 | 21.08-30.00 mm [27/32" - 1-3/16"] |
Zoom 0.950-1.36:1 |
|
| ET-EMS650 |
|
1.75-2.17 | 29.90-46.32 mm [1-3/16" - 1-13/16"] |
Zoom 1.35-2.10:1 |
|
| ET-EMT750 |
|
1.82-2.53 | 46.00-90.50 mm [1-13/16" - 3-9/16"] |
Zoom 2.10-4.14:1 |
|
| ET-EMT850 |
|
1.85-2.39 | 90.30-162.60 mm [3-9/16" - 6-13/32"] |
Zoom 4.14-7.40:1 |
For PT-MZ17KL / MZ14KL / MZ11KL Projectors
- Compatible Projectors:
- PT-MZ17KL / MZ14KL / MZ11KL
Throw Ratio Table
-
150-inch
Quick Reference Guide
| Compatible Projector |
Model Number | Product Image | F Number | Focal Distance [inch] |
Throw Ratio |
|---|---|---|---|---|---|
| MZ17KL MZ14KL MZ11KL |
ET-EMU100 |
|
1.9 | 7.23-7.73 mm [9/32" - 5/16"] |
Zoom 0.330-0.353:1 |
| ET-EMW200 |
|
1.84-2.14 | 10.80-12.52 mm [7/16" - 1/2"] |
Zoom 0.480-0.550:1 |
|
| ET-EMW300 |
|
1.84-2.24 | 12.31-15.43 mm [1/2" - 19/32"] |
Zoom 0.550-0.690:1 |
|
| ET-EMW400 |
|
11.84-2.24 | 15.30-21.10 mm [19/32" - 27/32"] |
Zoom 0.690-0.950:1 |
|
| ET-EMW500 |
|
1.80-2.35 | 21.08-30.00 mm [27/32" - 1-3/16"] |
Zoom 0.950-1.36:1 |
|
| ET-EMS600 / EMS650 |
|
1.75-2.17 | 29.90-46.32 mm [1-3/16" - 1-13/16"] |
Zoom 1.35-2.10:1 |
|
| ET-EMT700 / EMT750 |
|
1.82-2.53 | 46.00-90.50 mm [1-13/16" - 3-9/16"] |
Zoom 2.10-4.14:1 |
|
| ET-EMT800 / EMT850 |
|
1.85-2.39 | 90.30-162.60 mm [3-9/16" - 6-13/32"] |
Zoom 4.14-7.40:1 |
For PT-MZ16K Series Projector
- Compatible Projectors:
- PT-MZ16KL/MZ13KL/MZ10KL
Throw Ratio Table
-
150-inch
Quick Reference Guide
| Compatible Projector |
Model Number | Product Image | F Number | Focal Distance [inch] |
Throw Ratio |
|---|---|---|---|---|---|
| MZ16KL MZ13KL MZ10KL |
ET-EMU100 |
|
1.9 | 7.23-7.73 mm [9/32" - 5/16"] |
Zoom 0.330-0.353:1 |
| ET-EMW200 |
|
1.84-2.14 | 10.80-12.52 mm [7/16" - 1/2"] |
Zoom 0.480-0.550:1 |
|
| ET-EMW300 |
|
1.84-2.24 | 12.31-15.43 mm [1/2" - 19/32"] |
Zoom 0.550-0.690:1 |
|
| ET-EMW400 |
|
11.84-2.24 | 15.30-21.10 mm [19/32" - 27/32"] |
Zoom 0.690-0.950:1 |
|
| ET-EMW500 |
|
1.80-2.35 | 21.08-30.00 mm [27/32" - 1-3/16"] |
Zoom 0.950-1.36:1 |
|
| ET-EMS600 / EMS650 |
|
1.75-2.17 | 29.90-46.32 mm [1-3/16" - 1-13/16"] |
Zoom 1.35-2.10:1 |
|
| ET-EMT700 / EMT750 |
|
1.82-2.53 | 46.00-90.50 mm [1-13/16" - 3-9/16"] |
Zoom 2.10-4.14:1 |
|
| ET-EMT800 / EMT850 |
|
1.85-2.39 | 90.30-162.60 mm [3-9/16" - 6-13/32"] |
Zoom 4.14-7.40:1 |
For PT-MZ882 Series / PT-MZ880 Series Projector
- Compatible Projectors:
- PT-MZ882/MZ782/MZ682/MZ880/MZ780/MZ680
Throw Ratio Table
-
100-inch
Quick Reference Guide
| Compatible Projector |
Model Number | Product Image | F Number | Focal Distance [inch] |
Throw Ratio |
|---|---|---|---|---|---|
|
MZ882 MZ782 MZ682 MZ880 MZ780 MZ680 |
ET-ELU20 |
|
2.0 | 5.43-5.82 mm [7/32" - 15/64"] |
Zoom 0.330-0.353:1 |
| ET-ELW21 |
|
2.0 | 13.05 mm [1/2"] |
Fixed 0.764:1 |
|
| ET-ELW22 |
|
2.0-2.4 | 13.27-16.56 mm [17/32" - 21/32"] |
Zoom 0.786-0.983:1 |
|
| ET-ELW20 |
|
1.8-2.3 | 20.4-27.6 mm [13/16" - 1-3/32"] |
Zoom 1.21-1.66:1 |
|
| ET-ELS20 |
|
1.7-2.3 | 26.9-45.4 mm [1-1/16" - 1-25/32"] |
Zoom 1.61-2.76:1 |
|
| ET-ELT22 |
|
1.8-2.3 | 45.6-73.8 mm [1-13/16" - 2-29/32"] |
Zoom 2.72-4.48:1 |
|
| ET-ELT23 |
|
1.8-2.3 | 74.8-118.2 mm [2-15/16" - 4-21/32"] |
Zoom 4.44-7.12:1 |
For PT-EZ770 Series / PT-EZ590 Series Projectors
- Compatible Projectors:
- PT-EZ770Z/EW730Z/EX800Z
Throw Ratio Table
-
100-inch
- Compatible Projectors:
- PT-EZ590/EW650/EW550/EX620/EX520
Throw Ratio Table
-
100-inch
Quick Reference Guide
| Compatible Projector |
Model Number | Product Image | F Number | Focal Distance [inch] |
Throw Ratio |
|---|---|---|---|---|---|
| EZ770Z EW730Z EX800Z |
ET-ELW21 |
|
2.0 | 13.05 mm [1/2"] |
Fixed 0.764:1 |
| ET-ELW22 |
|
2.0-2.4 | 13.27-16.56 mm [17/32" - 21/32"] |
Zoom 0.786-0.983:1 |
|
| ET-ELW20 |
|
1.8-2.3 | 20.4-27.6 mm [13/16" - 1-3/32"] |
Zoom 1.21-1.66:1 |
|
| ET-ELS20 |
|
1.7-2.3 | 26.9-45.4 mm [1-1/16" - 1-25/32"] |
Zoom 1.61-2.76:1 |
|
| ET-ELT22 |
|
1.8-2.3 | 45.6-73.8 mm [1-13/16" - 2-29/32"] |
Zoom 2.72-4.48:1 |
|
| ET-ELT23 |
|
1.8-2.3 | 74.8-118.2 mm [2-15/16" - 4-21/32"] |
Zoom 4.44-7.12:1 |
|
| EZ590 EW650 EW550 EX620 EX520 |
ET-ELW31 |
|
1.7-2.0 | 10.46-13.61 mm [13/32" - 17/32"] |
Zoom 0.74-0.96:1 |
| ET-ELW30 |
|
1.7-1.99 | 13.09-17.03 mm [17/32" - 21/32"] |
Zoom 0.96-1.21:1 |
|
| ET-ELT30 |
|
1.7-2.24 | 31.34-56.79 mm [1-7/32" - 2-1/4"] |
Zoom 2.22-4.03:1 |
|
| ET-ELT31 |
|
1.7-2.3 | 56.41-101.66 mm [2-7/32" - 4"] |
Zoom 4.02-7.28:1 |
Throw Distance Calculator
Throw-Distance Calculator is a convenient way to estimate throw distance for any screen size using any lens-detachable Panasonic projector and compatible optional lens.
Note: Values are estimates only.
