4K Entry Displays in Seven Sizes that Flexibly Match Corporate Meeting Rooms/Educational Use

Entry4K UHD LCD Displays

CQE2 SeriesTH-98CQE2NEW / TH-86CQE2NEW / TH-75CQE2NEW / TH-65CQE2NEW /
TH-55CQE2NEW / TH-50CQE2NEW / TH-43CQE2NEW

Note: release date varies depending on country or region and model

Suitable for use in corporate meeting rooms and educational classrooms as well as for information display.

1: Actual resolution: 3840 x 2160p

2: 98CQE2 only

3: U model (US and Canada) only

TH-98CQE2: 98-inch class; 500 cd/m²; 1200:1; 4K (3840 x 2160)

TH-86CQE2: 86-inch class; 400 cd/m²; 1200:1; 4K (3840 x 2160)

TH-75CQE2: 75-inch class; 400 cd/m²; 1200:1; 4K (3840 x 2160)

TH-65CQE2: 65-inch class; 500 cd/m²; 1200:1; 4K (3840 x 2160)

TH-55CQE2: 55-inch class; 500 cd/m²; 1200:1; 4K (3840 x 2160)

TH-50CQE2: 50-inch class; 500 cd/m²; 5000:1; 4K (3840 x 2160)

TH-43CQE2: 43-inch class; 500 cd/m²; 1200:1; 4K (3840 x 2160)

Features

4K high-brightness panel offering high image quality and high visibility

Available in wide 7 sizes from 98-inch to 43-inch. The 4K LCD that projects detailed content clearly with 500 cd/m² brightness and wide viewing panel suitable for use in corporate conference rooms and educational facilities.

* TH-86/75CQE2: 400 cd/m²

Reliability and ease of installation adapted to diverse use cases

Supports both vertical and tilting installation. Enables 16 hours/day continuous operation. Equipped with 4 HDMI™, USB-C (15W), 3 USB-A, it can be easily installed without converters and switchers. Furthermore, the CQE2 series equipped with the built-in speaker.

* TH-98CQE2 : 24hours/day

System scalability to enable a wide range of system integration

The CQE2 series is equipped with Android™ OS, so possible to operate digital signage without STB/PC. Equipped with Wi-Fi functionality to wirelessly display images on the display from a PC or Android™ device¹. Control is possible via serial or LAN. Simultaneous control and batch management over a network are also possible.

1: Windows^® 10 PC or Android™ device with wireless functionality. Operation is not guaranteed on all devices.

Flexible installation to suit your space

Wide lineup from 98 to 43 inches models to suit your space, ranging from small corners such as a huddle room to the main display in a conference room. It can be installed horizontally or vertically, allowing you to choose the installation orientation according to the content.

Ensures high visibility even in bright rooms

500 cd/m2

The CQE2 series displays 4K resolution images at a brightness of 500 cd/m², ensuring high visibility even in bright environments.

* TH-86/75CQE2: 400 cd/m²

Ensures high visibility even in bright rooms

Elaborate 4K Picture Quality Down to the Tiniest Details

* Actual resolution: 3840 x 2160p

With approximately 8,290,000 pixels, about four times the pixels of a Full-HD display, images are highly detailed. This dynamic, large-screen display archives true-to-life finely nuanced images. The 4K display is an excellent choice for digital signage and meeting rooms.

Please visit "Why 4K" site.

Images Optimized for the Display Content

The CQE2 series comes with an extensive display menu to let you select the most suitable mode for the content to be displayed and the viewing environment.
You can select the best mode for the video source and the place of display.

Signage
Natural
Text
Game
Sports

Excellent Reliability Enable Continuous 16/7 Operation

In addition to being impact resistant, the CQE2 series is capable of constant, 16/7 operation. It offers reliable use in educational institutions, offices and stores.

* In case of long time, the moving image is recommended to be displayed. If you display a still picture for an extended period, the image retention might remain on the screen. However, image retention can gradually disappear by displaying a moving images.

* 98CQE2 supports 24-7 operation.

Choose the Installation to Match Your Application

There are screen sizes to match everything, from small rooms, such as huddle rooms, to large rooms. It can be installed horizontally or vertically, allowing you to choose the installation orientation according to the content. And installation is also possible at a forward inclination of up to 20 degrees to maintain legibility when mounted in high places.

* TH-98CQE2: Landscape/Portrait installation 20 degrees forward/backward

USB Type-C Connectivity

The CQE2 series has USB-C terminal (15W) that allows connection from mobile devices. 4K display, data transfer and charging of connected devices can be simultaneously conducted over a single cable with the USB-C port.

HDMI™ (x4) Connectivity

External devices can be connected and various contents can be displayed according to the usage environment with the HDMI™ (x4) video input terminals.

Wireless Display Function

The CQE2 series has been equipped* with Wi-Fi. You can transfer the screen of your PC without a connection cable.
This is convenient when replacing presenters during a conference or when a participant displays data from a PC.

* The 98, 86-inch models are dongle types, and not built-in types.

Images on screen are simulated.

PC Software Enables Even Easier and More Convenient Content Playback and Management

The CQE2 Series features a USB Media Player function that allows easy signage playback. Content Management Software is an application software for scheduling digital signage playback on a computer. It also allows power ON/OFF to be set.

* For more information about Content Management Software, please visit download software.

Play Content Automatically with Scheduling Function

Content Management Software for PC (free) enables easy playlist creation with media support including combinations of still and video images. You can set up schedules for playing and ending your media playlist at predetermined dates and times.

Convenient Playlist and Schedule Syncing

Playlists and schedules created with Content Management Software can be transferred to displays with USB memory or via LAN.

4K USB Media Player

Video and still images saved into USB media in advance can simply be inserted into the CQE2 series for automatic playback.

* The playable application format, GUI and operation procedure for the CQE2 series' Media Player function are different from those of other models.

Built-in TV TunerU model (US and Canada) only

A TV tuner is built-in, providing highly precise 4K images. A Sports mode is also equipped, ideal for live sports relays with dynamic images. And in addition to use in sports bars and restaurants, the CQE2 Series is optimal for refreshing office entertainment and information gathering during emergencies.
