PT-MZ20K SeriesPT-MZ20KL / PT-MZ17KL / PT-MZ14KL / PT-MZ11KL

Note: Volume and dimensions are approximate. Height is with legs at shortest position. Depth is without lens and protruding parts.

Introducing the world’s smallest and lightest LCD projector with 20,000 lm¹. Optimized optical efficiency has resulted in a 25 % increase in brightness from the same body size as the 16,000 lm² PT-MZ16KL. The compact and sophisticated design harmonizes with open halls and hybrid learning spaces. Images from PT-MZ20K Series are easily visible even in brightly lit areas, making it suitable for a wide range of applications, from large-screen projection at lectures and seminars to powerful exhibition presentations at museums.

1 Light output of PT-MZ20KL. As of March 2023, based on publicly available dimensions, weight, and operation noise values for LCD laser projectors with 20,000 lm brightness and above. Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped.

2 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped.

Pure White Generator, developed by Panasonic Connect, contributes to rich color reproduction at high brightness of up to 20,000 lm¹. Efficient light collection uses a multi-reflection system to minimize loss of light-source energy noticeable with conventional systems. It achieves an optimal color balance without sacrificing brightness for realistic and accurate color expression.

1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped.

Dynamic Contrast NX, a further evolution of Dynamic Contrast, uses a newly developed video-scene analysis circuit to recognize differences in brightness and darkness more precisely than before.

Light and compact body improves loading efficiency and reduces CO₂ emissions associated with transport. In addition, MZ20KL boasts the world’s lowest power consumption of any projector in its class¹ to reduce resources required for daily operation. Laser light source and filter don’t need to be replaced for 20,000 hours², minimizing use of consumable parts and other waste. From transportation to operation and maintenance, the environmentally friendly design reduces labor and costs while supporting CSR, SDGs, and other green initiatives.

1 As of March 2023, based on publicly available power consumption values for LCD laser projectors with 20,000 lm brightness and above according to internal research.

2 Around this time, light output will have decreased to approximately 50 % of its original level ([PICTURE MODE]: [DYNAMIC], [DYNAMIC CONTRAST] set to [3], temperature 30 °C [86 °F], elevation 700 m [2,297 ft] with 0.15 mg/m³ of particulate matter). Replacement of parts other than the light source may be required in a shorter period. Estimated time until light output declines to 50 % varies depending on environment. Filter cleaning cycle varies depending on environment. Filter can be washed and reused up to two times.

Multi-Laser Drive Engine ensures stable projection even if light-source problems occur. The projector is equipped with multiple modules consisting of many laser diodes, and in the unlikely event one of the elements malfunctions, Panasonic Connect’s unique Failover Circuitry is activated so that projection can continue with virtually no reduction in brightness. This allows the projector to be used with peace of mind in situations where a drop in brightness could affect important presentations, such as large-scale lectures and seminars.

To achieve high brightness and stable operation, we adopted a liquid-cooling system originally developed for our DLP™ projection systems. This efficient design circulates cooling liquid to the light-source modules directly, preventing temperature increases associated with high-brightness projection. Combined with a highly reliable original dustproof structure, the system enables stable performance even in hot, dusty environments.

Backup Input¹ function enables seamless projection even if the input signal is disrupted. With HDMI 1 set as the primary input and HDMI 2 set as the secondary input, the projector switches to HDMI 2 in as little as 0.3 seconds² if the signal to HDMI 1 is disrupted. This improves reliability and ensures stable operation in environments where video presentation must not be interrupted.

1 Primary Input (HDMI 1) and Secondary Input (HDMI 2) terminal assignment is fixed. Input signals to primary and secondary inputs must be identical.

2 Varies depending on the Backup Input mode and the connected external device.

Information Monitor is located on the main unit’s control panel and displays information such as temperature, voltage, operating hours, and input signals in real time. If a projector error occurs, the error number and associated details are immediately reported. The status of the main unit can be easily checked, and quick recovery from trouble is made possible.

Data cloning function allows the user to copy settings and adjustment values from a Main projector to Sub projectors via LAN¹ or USB memory device. This function reduces the time and effort required when setting up multiple projectors.

Note: Data-cloning is supported among models in the same series with the same resolution. Excludes passwords, projector ID, and network settings.

1 Data can be copied to a maximum of 99 Sub projectors via LAN.

Smart Projector Control app¹ allows you to control the projector from a smartphone. By scanning the QR code² displayed on the OSD menu screen or Information Monitor and connecting to wireless LAN, switching input signals and other functions can be performed from a mobile device. In addition to being able to control up to 64 devices simultaneously, it also supports lens adjustment, test-pattern switching, and focus adjustment using your device’s camera³ from a distance of 30 m⁴. For more information, please click here.

1 Check device compatibility at the App Store or the Google Play store.

2 Requires optional AJ-WM50 Series Wireless Module (sold separately). Product availability may vary by country or region.

3 Some devices do not support projector autofocus function.

4 When projecting a 300-inch image. Maximum distance is 3 m (10 ft) for a 100-inch image.

With built-in Geometric Adjustment, various distortions on the screen can be corrected via remote control. In addition to trapezoidal distortion resulting from angled projection, Curved Screen Correction fixes distortion caused by projection onto curved surfaces. Corner Correction allows the user to specify four screen corners, such as the upper right and lower right, for correction. Screen proportions can be maintained and corrections can be saved as data.

In addition to built-in Geometric Adjustment function, Free Grid allows pinpoint correction of local distortion within the screen. Grids between 2 x 2 and 17 x 17 lines can be selected to allow point-by-point correction, or batch correction by specifying vertical and horizontal lines. Correction data is maintained even after changing the number of grids or points, allowing smooth transition from basic to detailed correction. This convenient function allows adjustment of special screens, such as irregular or uneven wall surfaces, with the remote control.

For advanced screen adjustment, PT-MZ20K Series features Geometry Manager Pro software¹ which expands built-in functions and enables adjustment from a PC. In addition to the standard functions included in the software, PT-MZ20K Series has built-in upgrade kits that allow access to all functions without license activation. PT-MZ20K Series offers unparalleled smoothness to reduce labor-intensive adjustment with camera-based² geometric distortion correction, edge-blending, color-matching, stacking, and automatic adjustment of brightness and black levels.

1 Visit PASS to register your projector and download free Geometry Manager Pro software for Windows^® (upgrade kits included). Visit the Panasonic Geometry Manager Functions webpage for more information.

2 Compatible cameras comprise Nikon D5200/D5300/D5500/D5600/D7500. Use of Auto Screen Adjustment function with these cameras requires installation of Auto Screen Adjustment Plug-in (a free camera driver available from PASS). Use of Auto Screen Adjustment function with D7500 requires Geometry Manager Pro Ver. 6.1.10 or later and Auto Screen Adjustment Plug-in Ver. 5.1.10 or later.

With conventional black level correction, only the width and angle of the black border are specified for correction, making edge-blending on curved screens difficult. To solve this problem, PT-MZ20K Series is equipped with a function that allows the shape of black borders to be adjusted to match the screen shape. Using up to 17 points, flexible black level correction is possible even on curved screens, enhancing the sense of cohesion in multi-screen applications.

With Remote Preview LITE¹, you can check input images in advance even when it’s not possible to project content, such as outdoors during the daytime or during performance rehearsals. When your PC and the projector are connected to the network, you can use a web browser or Multi Monitoring & Control Software to display thumbnail images of the input video. Check content even when the shutter is in use or the projector is in Standby² to quickly identify any problems between the source device and the projector for faster recovery.

1 Requires Multi-Monitoring & Control Software Version 3.3 or later available free here. For more information, click here.

2 Projector must be set to Pre-Show Mode.

Panasonic Connect’s unique image quality correction circuitry reproduces details more clearly and sharply. It analyzes video signal frequencies in each scene and adjusts for optimal sharpness based on information extracted from the signal. Compared to conventional image processing technology, this system reproduces images with an even more natural and three-dimensional feel.

A variety of optional lenses (eight models² in total) are available to support a range of screen sizes between 80 and 600 inches, allowing you to select the optimal lens for your projection needs. These lenses are equipped with a temperature sensor and automatically correct focus in conjunction with the projector’s AFO² function. This technology maintains a sharp image regardless of the brightness of the content, eliminating need for manual focus adjustment. Of course, powered lens-shift and zoom adjustment is also supported via remote control or Smart Projector Control app³.

1 Specifications vary depending on the lens. Please refer to the Operating Manual for details.

2 PT-MZ17KL/MZ14KL/MZ11KL are also compatible with previously released ET-EMS600/EMT700/EMT800 lenses.

3 Check device compatibility at the App Store or the Google Play store.
