Installation1-Chip DLP™ Projectors

PT-RQ7 SeriesPT-RQ7L / PT-RQ6L / PT-RZ7L / PT-RZ6L
[PT-RZ7L/RZ6L AVAILABLE FROM CY2024 Q4]

Immersive for All: Light & Compact 1-Chip DLP™ 4K1 Projectors Maximize Your Efficiency

PT-RQ7 Series
PT-RQ7L PT-RQ6L PT-RZ7L PT-RZ6L
7,500 lm2 /
7,500 lm (ANSI)3 /
7,700 lm (Center)4
6,500 lm2 /
6,500 lm (ANSI)3 /
6,700 lm (Center)4
7,500 lm2 /
7,500 lm (ANSI)3 /
7,700 lm (Center)4
6,500 lm2 /
6,500 lm (ANSI)3 /
6,700 lm (Center)4
4K (3840 x 2160 pixels)5 WUXGA (1920 x 1200 pixels)
DLPSOLID SHINE LASER4K1QUAD PIXEL DRIVE1240 Hz64K DIGITAL LINK
4K Accepts Signal7INTEL®360°24/7 OparationGeoPro
01 Key Feature

Seamless Visuals, Endless Possibilities

Quad Pixel Drive1 creates smooth 4K1 images without visible pixels or gridding, ideal for immersive 360° mapping attractions. Dynamic Contrast, Rich Color Enhancer, and Digital Art Mode bring out the realism of high-quality content. Project 1080/240p video6 and, with the ET-SWR10 kit8, seamlessly blend content and motion in real-time.

More Information

02 Key Feature

Compact & Expandable for Easy Installation

At just 16.6 kg (36.59 lbs) and about 29% smaller than our RZ790/RZ690 models, the RQ7 Series eases the logistical burden. Optional function boards9 for the Intel® SDM standard-compatible SLOT, including our
ET-SBFMP10 media processor, simplify complex layouts. Optional DLE Series lenses smooth the transition to 4K1 production.

More Information

03 Key Feature

Eco-Friendly Innovation with Proven Reliability

The optical engine and light-source module comply with the IP5X Dust Protected (IEC 60529) standard10, while a filterless design contributes to 20,000 hours11 of maintenance-free operation. Other aspects include using plastic parts containing about 73% recycled resins12 and an Eco Boost mode that maintains perceived brightness while reducing energy consumption.

More Information

1 PT-RQ7L/RQ6L only.

2 When ET-DLE170 is attached. Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped.

3 Measurement, measuring conditions, and method of notation all comply with American National Standards Institute standards. Value is the average of all products when shipped.

4 Average light-output value of all shipped products measured at the center of the screen in NORMAL Mode.

5 Maximum physical resolution of 4K (3840 x 2160) with Quad Pixel Drive [ON].

6 PT-RQ7L/RQ6L only. Supports input signals up to 1080p. The display frame rate corresponds to the input signal frame rate. When using the PT-RQ7L/RQ6L to display 1080/100p, 1080/120p, or 1080/240p content, edge blending and geometric adjustment cannot be used.

7 Input signals to the PT-RZ7L/RZ6L are converted to the projector’s display resolution upon playback. YPBPR 4:2:0 format only for 4K/60p and 4K/50p signals input via DIGITAL LINK.

8 PT-RQ7L/RQ6L only. Optional ET-SWR10 Real-Time Tracking Projection-Mapping System is sold separately. For more information, please click here.

9 Optional proprietary and third-party function boards compatible with the Intel® SDM standard-compatible SLOT are sold separately. Panasonic cannot guarantee the operation of third-party devices.

10 The Dust Protected performance of this unit is not guaranteed to be free from damage or failure under all conditions (environment with conductive dust, etc.). Please use an enclosure in environments with smoke containing oil, salt, and moisture.

11 Around this time, the light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast Contents, [NORMAL] Mode, [PICTURE MODE] set to [DYNAMIC], Dynamic Contrast [3], temperature 35 °C (95 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of airborne particulate matter. Panasonic recommends a checkup at the point of purchase after about 20,000 hours. Light-source lifetime may be reduced depending on environmental conditions. Replacement of parts other than the light source may be required in a shorter period. Estimated maintenance time varies depending on the environment.

12 By weight of the total mass of plastic parts in the projector main unit. Excludes projection lenses, printed circuit boards, labels, cables, connectors, electronic components, color sensor cases, optical components, ESD components, EMI component adhesives, and coatings.

Where Performance Meets Efficiency

Meet the RQ7 Series

RQ7 Series redefines 4K1 projection, blending spectacular visuals with unparalleled efficiency. This compact 1-Chip DLP™ projector creates an entrancing experience rich in contrast and color through exclusives such as Quad Pixel Drive1 and Rich Color Enhancer. But it’s Panasonic’s integration insight that sets it apart, with labor-saving innovations to streamline workflow. From automated multi-projection adjustment to effortless app control, the RQ7 Series makes it easy to realize your vision in museums, galleries, and beyond.

1 PT-RQ7L/RQ6L only.

Seamless Visuals, Endless Possibilities

Smooth and Dimensional 4K1 Video

Quad Pixel Drive1 produces smooth 4K1 images with a fascinating sense of depth. It meets the demand for absolute realism in immersive media spaces by creating detailed 4K1 images without visible pixels or gridding, even when viewed up close. Captivate your guests with an engaging visual experience that illuminates the creator’s world and elevates your storytelling.

1 PT-RQ7L/RQ6L only.

Rich Color Enhancer Brings the Creator’s Work to Life

Rich Color Enhancer is an original 2-mode color optimization technology. Dynamic Mode balances brightness and color for clear visibility in bright environments. Standard Mode optimizes color reproduction by expanding red-channel output for vibrant red expression. This is critical for the accurate and immersive reproduction of artwork and other color-rich content.

Rich Color Enhancer for Vivid, Accurate Colors

Digital Art Mode Increases Visual Impact

Digital Art Mode is a new picture mode that optimizes the presentation of high-quality digital artwork in museums, galleries, and immersive entertainment spaces. This mode allows you to easily enhance projection quality, emphasizing high contrast and vivid color reproduction for a more impactful viewing experience.

Digital Art Mode Increases Visual Impact

Note: Graphic is simulated for illustrative purposes only.

Smooth 1080/240p1 Playback

RQ7L/RQ6L can play 1080/240p1 video with an input-to-output latency of 8 ms2, smoothly reproducing fast-paced action such as eSports with minimal motion blur. The projectors also work with Panasonic’s optional ET-SWR10 Real-Time Tracking Projection-Mapping System3. With this ready-to-use Software Development Kit (SDK), you can link with infrared cameras and project images onto fast-moving objects at 240 Hz1, smoothly and seamlessly combining visual content and physical motion within your XR attraction.

1 PT-RQ7L/RQ6L only. Supports input signals up to 1080p. The display frame rate corresponds to the input signal frame rate. When using the PT-RQ7L/RQ6L to display 1080/100p, 1080/120p, or 1080/240p content, edge blending and geometric adjustment cannot be used.

2 Varies depending on the input signal, peripheral devices, and other factors.

3 Optional ET-SWR10 Real-Time Tracking Projection-Mapping System is sold separately. For more information, please click here.

Compact & Expandable for Easy Installation

Light, Quiet, and Easy to Manage

With a compact body about 29% smaller by volume and 22% lighter than the existing RZ790/RZ690 projector models, the RQ7 Series saves resources and reduces your carbon footprint in transport, storage, and installation. It can be easily carried by one person, smoothing multi-projection logistics. Furthermore, the efficient cooling system reduces operating noise to as little as 31 dB1, ensuring your audience stays focused on the experience and not the equipment creating it.

Light, Quiet, and Easy to Manage

1 For the PT-RQ6L/RZ6L in QUIET Mode. Please see the specifications for more information.

Compatible with Existing DLE Series Lenses

The RQ7 Series is compatible with Panasonic’s DLE Series projection lenses, offering versatility for diverse production layouts and making the transition to 4K1 more cost-effective for businesses with existing lens inventories. The projector’s strengthened lens mounter now supports the ET-DLE020G/ET-DLE020 Ultra-Short-Throw Zoom Lens without requiring a bracket2, streamlining installation. These lenses feature powered zoom3, focus, and vertical/horizontal lens shift, conveniently controllable via remote or the Smart Projector Control app4.

1 PT-RQ7L/RQ6L only.

2 The PT-RQ7 Series is compatible with the ET-DLE020 (Lens Fixed Attachment bracket included) and ET-DLE020G (Lens Fixed Attachment bracket not included). When using the ET-DLE020, the included bracket is not required.

3 Excluding fixed-focus lenses.

4 Available free from the App Store or the Google Play Store. Check device and OS compatibility before downloading and installing the app.

Compatible with Existing DLE Series Lenses

Supports New Media Processors to Simplify Multi-Projection

The RQ7 Series works with Panasonic’s ET-FMP50 Series media processors to simplify multi-projection complexity. The processors, which comprise box-type and function board-type for the projector's Intel® SDM standard-compatible SLOT, feature automatic camera-based1 warping/blending and 4K media playback capabilities. For more information, please click here.

1 Compatible cameras (sold separately) comprise NIKON® D5200/D5300/D5500/D5600/D7500/Z50.

ET-FMP50

Wide Scalability with Intel® SDM Standard-Compatible SLOT

The RQ7 Series is compatible with optional proprietary and third-party function boards that insert into its Intel® SDM standard-compatible SLOT, making it easy to adapt, scale, and expand your projector’s connectivity. For a list of compatible function boards, please click here.

Wide Scalability with Intel® SDM-ready Slot

Note: The terminal layout pictured is for reference only. Optional proprietary and third-party function boards are sold separately. Panasonic cannot guarantee the operation of third-party devices. The transmission method to the slot must be by HDMI™ signal.

Smart Projector Control App Smooths Your Workflow

Smart Projector Control app1 lets you control up to 64 projectors from your phone or tablet. It enables projector setting adjustment from your device, which is useful when OSD menu projection isn’t possible. Other functions include test pattern selection, shutter control, Web Control UI access, lens settings adjustment, brightness locking, and focus adjustment via the device camera2 from distances of up to 30 m (98 ft)3. The app enables swift connection to the projector via QR Code scanning4, eliminating password/SSID entry. For more, please visit the Smart Projector Control webpage.

Smart Projector Control App

1 Available free from the App Store or the Google Play Store. Check device and OS compatibility before downloading and installing the app.

2 Some devices do not support the projector autofocus function.

3 When projecting a 300-inch image. The maximum distance is 3 m (10 ft) for a 100-inch image.

4 Requires optional AJ-WM50 Series Wireless Module (sold separately). Product availability may vary by country or region.

Geo Pro Automates Screen Adjustment and Blending

RQ7 Series offers built-in geometric adjustment tools, including a point-based Free Grid function to correct localized screen distortion. It ships with preactivated upgrade kit licenses for Geo Pro software. These comprise the ET-UK20 Geometry Manager Pro Software Upgrade Kit, which expands functionality and adds sophisticated line, shape, and bitmap masking tools, and the ET-CUK10 Auto Screen Adjustment Upgrade Kit, which automates edge-blending including brightness, color, and black level adjustment via a camera.

MaskingFunction (Custom Masking)

Note: Visit PASS to register your projector and download free Geometry Manager Pro software for Windows®. Compatible cameras comprise Nikon® D5200/D5300/D5500/D5600/D7500. Other conditions apply. Please visit PASS for more information.

Contrast Sync and Shutter Sync via LAN Cable Only

Traditionally, Dynamic Contrast control operated individually for each projector in a multi-screen system, leading to step noise in blends due to variations in the Average Picture Level (APL). Panasonic’s Contrast Sync resolves this issue by using the average APL of all projectors in the system, resulting in a seamless multi-screen image. The RQ7 Series is the first Panasonic projector to support Contrast Sync via LAN cable only, eliminating the need for a serial cable connection and reducing system complexity. Additionally, the shutter timing of all sub-projectors is synchronized with the main projector via the LAN connection, ensuring cohesive fade-in/fade-out effects across the entire projection.

Contrast Sync and Shutter Sync via LAN Cable Only

Import and Save Custom Test Patterns

In addition to 10x built-in test patterns, users can import and save 4x custom images in JPEG, BMP, or PNG format to an RQ7 Series projector via its Web Control UI or USB memory device for use as test patterns, start-up logos, and no-signal screensavers. Installers can calibrate projectors using client content or custom images without connecting to a media source device.

Import and Save Custom Test Patterns

Note: This function replaces Logo Transfer Software.

Quickly Find the Projection Angle with Angle Monitor

The RQ7 Series supports 360° projection angles, enabling image mapping on floors, walls, and 3D objects. However, aligning the projection angle with the design simulation can be challenging and requires two people. The projectors feature a built-in gyro sensor detecting changes in the projector’s pitch and roll angles, graphically displayed in the OSD settings menu. Installers can adjust the projection angle without needing assistance.

Quickly Find the Projection Angle with Angle Monitor

Note: The displayed values are based on the results of angle sensor detection and may differ from the actual projection angle. They are for reference only, and accuracy is not guaranteed.

Refreshed Web Control User Interface

The RQ7 Series features an updated Web Control UI supporting dark and light modes. Information within the UI is reorganized for improved visibility. You can set projector command schedules such as power on/off, view the projector’s OSD settings menu on the PC screen, and customize device status info on the Home screen. Other updates include adaptive screen sizes and enhanced mobile versions, empowering efficient management.

GUI

Eco-Friendly Innovation with Proven Reliability

Dust-Resistant Optical Engine

The RQ7 Series’s optical engine and laser light source conform to the IP5X Dust Protected (IEC 60529)1 standard. This eliminates the need for a filter and enables 20,000 hours2 of maintenance-free projection. Reliability is proven by accelerated dust-chamber testing in significantly dustier conditions than those in which some competitive products are tested.

Hermetic Optical Engine and Liquid Cooling System
Hermetic Optical Engine and Liquid Cooling System

1 The Dust Protected performance of this unit is not guaranteed to be free from damage or failure under all conditions (environment with conductive dust, etc.). Please use an enclosure in environments with smoke containing oil, salt, and moisture.

2 Around this time, the light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast Contents, [NORMAL] Mode, [PICTURE MODE] set to [DYNAMIC], Dynamic Contrast [3], temperature 35 °C (95 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of airborne particulate matter. Panasonic recommends a checkup at the point of purchase after about 20,000 hours. Light-source lifetime may be reduced depending on environmental conditions. Replacement of parts other than the light source may be required in a shorter period. Estimated maintenance time varies depending on the environment.

Eco Boost Maintains Perceived Brightness with Reduced Consumption

A new Eco Boost mode further reduces energy consumption when Dynamic Contrast is enabled while maintaining perceived brightness.

Eco Boost Mode: Maintain Brightness and Reduce Power Consumption

Note: Graphic is simulated for illustrative purposes only.

Reducing Environmental Impact with Recycled Materials

In addition to using responsibly procured materials, the plastic parts in the main projector body contain about 73%1 recycled resins, reducing the utilization of virgin materials. By supporting eco-friendly manufacturing processes and pursuing recycling-based programs at end-of-life, your organization helps minimize environmental impact throughout the product’s lifecycle.

1 By weight of the total mass of plastic parts in the projector main unit. Excludes projection lenses, printed circuit boards, labels, cables, connectors, electronic components, color sensor cases, optical components, ESD components, EMI component adhesives, and coatings.

Backup Input Redundancy

Two identical signals can be simultaneously transmitted to HDMI™ 1 (Primary) and HDMI™ 2 (Backup). If transmission to the primary input is interrupted, the projector switches to the backup automatically in a minimum of 0.3 seconds1 without screen-blanking. This layer of insurance gives greater peace of mind during events where image display can’t be interrupted.

Backup Input Redundancy

1 Varies depending on the Backup Input mode and the connected external device.

Note: Primary and backup terminal assignments are fixed. The input signals to primary and backup inputs must be identical.

Multi-Laser Drive Engine Enhances Reliability

Multiple laser modules are equipped with Failover Circuitry. In the unlikely event a single diode fails, Failover Circuitry continues to supply electricity to the functional diodes in the series, minimizing brightness loss. If the same issue were to occur in projectors without Failover Circuitry, all diodes in the module might shut down, resulting in a significant loss of brightness.

Reduce Errors with Remote Preview LITE

Remote Preview LITE allows projectionists to confirm connectivity and assess image adjustments before the video is projected by viewing preview thumbnails on a laptop. This is valuable at live events where checking content on the screen is limited due to soundchecks and other logistical factors. Accessible via software or web browser, it works with the projector in Standby1 or with the shutter on, minimizing errors before performances.

Reduce Errors with Remote Preview LITE

1 Projector must be set to Pre-Show Mode.

Note: Requires Multi-Monitoring & Control Software Version 3.3 or later available free here. For more information, click here.

Other Features

  • ・ Supports Art-Net DMX, PJLink™, Crestron Connected® V2,
    Crestron® XiO Cloud, and Extron XTP®
  • ・ Supports IPv61 network protocol
  • ・ Supports widescreen 21:9 input signals
  • ・ USB port for DC 5 V/2 A power supply, optional AJ-WM50 Series
    Wireless Module, and data transfer
  • ・ Compatible with the Multiple PJ Firmware Batch Update Tool
  • ・ Data-Cloning Function2 via LAN or USB
  • ・ Quick Start and Quick Off
  • ・ Multi-screen Support System
  • ・ Multi-Unit Brightness and Color Control
  • ・ DICOM Simulation Mode
  • ・ Waveform Monitor Function

1 Optional AJ-WM50 Series Wireless Module is not compatible with IPv6.

2 Data cloning is supported among models in the same series with the same resolution. Passwords, projector ID, and network settings are excluded.
