Installation1-Chip DLP™ Projectors

PT-FRQ60 SeriesPT-FRQ60 / PT-FRQ50

Detailed 4K Images at up to 6,000 lm: Delivering Insightful Experiences from a Compact 1-Chip DLP™ Platform

PT-FRQ60 Series
6,000 lm1 / 6,200 lm (Center)2 5,200 lm1 / 5,400 lm (Center)2
(3840 x 2160 pixels)3
(3840 x 2160 pixels)3
01 Key Feature

Smooth and Detailed
4K Image Quality

Quad Pixel Drive creates sharp, detailed 4K images with Rich Color Enhancer achieving vivid, accurate color. High-speed processing supports 240 Hz/1080p frame rates with latency of 8 ms or less4 for smooth, grid-less images.

More Information

02 Key Feature

Flexible, Simple to Use,
and Easy to Integrate

V/H Lens-Shift and 2.0x zoom enhance installation flexibility while two CEC-compatible HDMI® inputs and DIGITAL LINK integrate into 4K infrastructure. Free Grid simplifies operation of Geometric Adjustment functions using only the projector remote control.

More Information

03 Key Feature

Highly Reliable Low-
Maintenance Projection

Filterless heat-pipe-based cooling and hermetically sealed optical block support 20,000-hour5 maintenance-free projection. Optional Early Warning6 functions streamline management and enhance reliability in museums, classrooms, and offices.

More Information

1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped. When [PICTURE MODE] is set to [DYNAMIC] and [LIGHT POWER] is set to [NORMAL].

2 Average light-output value of all shipped products measured at center of screen in NORMAL Mode.

3 With Quad Pixel Drive.

4 Display frame rate corresponds to the input signal frame rate. Geometric adjustment features must be disabled.

5 Around this time, light output will have decreased to approximately 50 % of its original level ([PICTURE MODE]: [DYNAMIC], [DYNAMIC CONTRAST] set to [2], temperature 30 °C (86 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of particulate matter).

6 Early Warning functions are bundled with free Multi Monitoring & Control Software (paid license required after 90-day trial period elapses).

Smooth and Detailed 4K Image Quality

Quad Pixel Drive for Detail-rich 4K Images with High Frame Rates

Quad Pixel Drive, Panasonic’s original 2-axis pixel-quadrupling technology, rapidly shifts each pixel vertically and horizontally to produce sharp, clear, and detail-rich 4K images for a maximum resolution of 3840 x 2160 pixels (16:9). Combined with the DMD’s high pixel-density and narrow aperture ratio, Quad Pixel Drive creates smooth, filmlike images with a superior sense of depth and definition, allowing viewers to retain complex information.

Pixel Quadrupling Technology

Rich Color Enhancer Produces Vivid, Accurate Colors

Rich Color Enhancer is an original Panasonic color optimization technology for 1-Chip DLP™ projectors that offers two selectable modes. Dynamic Mode balances brightness and color for clear image visibility in well-lit environments. Standard/Graphic Mode optimizes color reproduction performance by adjusting color-wheel timing to expand red-channel output, leading to more naturally vibrant red expression. Colors are deep, rich, and accurate, faithfully reflecting the content creator’s artistic intent.

Rich Color Enhancer

Smooth Playback of 240 Hz Content

The projector smoothly plays 240 Hz/1080p video content with a minimal input-to-output latency of just 8 ms or less1, perfect in any application where fast response and fluid motion are important. PT-FRQ60 Series also works with Panasonic’s optional ET-SWR102 Real-Time Tracking
Projection-Mapping System, a ready-to-use Software Development Kit (SDK) that enables image projection onto fast-moving objects at up to 240 fps, making it easy to add lifelike interactivity to your museum exhibit.

1 Display frame rate corresponds to the input signal frame rate. Geometric adjustment features must be disabled.
2 ET-SWR10 is used in conjunction with third-party devices (sold separately). Compatibility with third-party devices cannot be guaranteed. Other limitations apply. For more information, visit the ET-SWR10 webpage.

Dynamic Contrast Elevates Image Realism

Dynamic Contrast directly modulates light output to achieve high contrast with less power consumption. Digitally controlled frame-by-frame
scene-linking modulation ensures precise light output adjustment for accurate contrast even when bright and dark scenes frequently interchange.

Flexible, Simple to Use, and Easy to Integrate

Flexible 2.0x Zoom Lens with Wide-Range V/H Lens-Shift

Versatile 2.0x optical zoom lens clears a path to stress-free installation by expanding throw-distance flexibility, giving you more freedom to choose a mounting position for the projector. Wide-range V/H Lens-Shift (Vertical: +71 %, -48 % and Horizontal: +34 %, -27 %) locates the image as desired when the ideal projector placement isn’t possible, such as in rooms with high ceilings or for projection at an angle. Adjustments are easily performed via joystick on the front panel.

Wide-Range 2.0x Zoom Lens with Lens-Shift

Geometric Adjustment with Free Grid for Screen Adjustment via Remote Control

Free Grid simplifies operation of select Geometric Adjustment functions built into the projector. Using only the projector remote control, with no need of a connected PC, installers can correct image distortion caused by uneven surfaces or irregular objects on flat or curved screens. A grid is overlaid on the projected image, allowing the installer to reshape distorted areas by adjusting the position of node or V/H line control-points. Grids of 2 x 2,
4 x 4, 8 x 8, or 16 x 16 lines are selectable according to required granularity, and work progress is saved automatically. Grid and control-point colors are selectable to ensure clear visibility over the image.

Geometric Adjustment with Free Grid Correction via Remote Control

Remote Preview Lite

Remote Preview Lite1 allows the projectionist to check signal connectivity and to evaluate changes to the image when selected projector image adjustment settings are changed by previewing input video on a laptop screen. Remote Preview Lite works even when the projector is in Standby Mode and eliminates need for on-screen projection immediately before the presentation commences. It reduces chance of display issues before the performance, and if an error is detected, helps narrow down the possible cause to the input signal chain.

1 Requires Multi Monitoring & Control Software Version 3.2 or later.

Features 2x HDMI® CEC-Compatible Inputs for Easy Operation

Two 4K-ready HDMI inputs support CEC commands from compatible devices, allowing the projector to turn ON/OFF with the source device. Add optional Wireless Presentation System PressIT1 and share content from almost any device with a single press of a button. As with other compatible streaming devices, PressIT can be powered via built-in 5 V/2 A USB-DC terminal for self-contained on-ceiling installation. Compatibility with HDCP 2.3-protected 4K/60p video promotes smooth integration into your existing 4K-ready system infrastructure.

Powers ON/OFF with CEC-compatible source device via HDMI®
Content transmitted wirelessly

1 Availability may vary by country or region. For more information on Wireless Presentation System PressIT, please click here.

2 Device’s USB Type-C terminal requires support for DisplayPort™ ALT Mode (image output function) and DC power supply (5 V/0.9 A). Refer to the product manual for more information. Android™ devices require a dedicated app.

Note: Accessories sold separately. Operation with third-party devices cannot be guaranteed.

4K DIGITAL LINK Connection and Separate LAN Terminal

4K DIGITAL LINK transmits uncompressed 4K/60p (4.2.0) video1, audio2, and control commands through a single CAT 5e or higher STP cable for distances of up to 50 m3. Optional ET-YFB200G DIGITAL LINK Switcher4 or ET-YFB100G Digital Interface Box4 simplify installation, reduce cabling and associated cost, and enhance system reliability. Alternatively, you can transmit 100Base-TX or 10Base-T compatible control signals via a separate LAN terminal, freeing up the 4K DIGITAL LINK connection for video-signal transmission.

1 4K input signals are resized to the projector’s resolution.

2 Audio transmission depends on model’s audio capability.

3 150 m (492 ft) transmission available with ET-YFB200G DIGITAL LINK Switcher for signals up to 1080p.

4 Optional ET-YFB200G DIGITAL LINK Switcher and ET-YFB100G Digital Interface Box are not compatible with 4K signals.

Highly Reliable Low-Maintenance Projection

Multi-Laser Drive Engine with Unique Failover Circuitry

Failover Circuitry1 limits brightness loss in the unlikely event of a single diode failure. Multi Laser Drive Engine2 features redundant laser modules that maintain image display even if a laser module fails. Failover Circuitry provides an invaluable layer of insurance in situations where image display must not be interrupted.

Multi-Laser Drive Engine with Failover Redundancy Circuits

1 Specifications vary depending on projector model.

2 Rate of brightness decrease varies depending on projector model.

20,000 Hours1 of Maintenance-Free Operation

To assure stable and reliable continuous operation, Panasonic implements a refined heat-pipe-based cooling system within the projector’s compact, easy-to-manage body dimensions. This filterless cooling system draws heat away from the optical block, which is hermetically sealed to prevent dust ingress in compliance with the industry’s toughest dust-proofing guidelines. Low-degradation laser modules, inorganic phosphor wheel, and filterless cooling system design contribute to 20,000 hours1 of maintenance-free projection.

Particulate Matter per Cubic Meter in Different Environments

1 Around this time, light output will have decreased to approximately 50 % of its original level ([PICTURE MODE]: [DYNAMIC], [DYNAMIC CONTRAST] set to [2], temperature 30 °C (86 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of particulate matter).

24/7 Continuous Operation

Supported by high-efficiency liquid cooling system, hermetically sealed and dust-resistant optical block, and low-degradation diodes grouped into multiple modules, SOLID SHINE Laser projectors can operate reliably 24 hours a day. These projectors are suited to continuous projection in exhibition and public display applications.

Multi Monitoring & Control Software with Optional Early Warning Functions

Panasonic’s free AV management software for Windows® PC lets you monitor and control up to 2,048 compatible display devices of any brand via LAN to reduce maintenance hassle within display networks of any scale. The software enables status monitoring, control-command execution, content playlist delivery, playback scheduling, and system map visualization. A free 90-day trial of optional Early Warning functions is included and adds extra functionality. It notifies the operator in the event of a playback or device error, and sends alerts when symptoms of trouble are detected. Maintenance reminders streamline device management. Operational reports can be generated and exported as a text file. The software links with compatible network cameras for live screen-monitoring, and you can also monitor device status remotely from a tablet via VPN. Software data can be acquired via Web API and installed onto an existing control application.

Multi Monitoring & Control Software with Optional Early Warning Functions

Note: Download Multi Monitoring & Control Software here. Purchase an optional license at PASS to continue using Early Warning functions after the free trial expires. Some functions require software Version 3.2 or later.

Other Features

Reduces Distractions for Better Focus and Immersion

When background noise must be kept to a minimum, Quiet Mode supports almost indiscernible 28 dB1 operation, limiting distractions in immersive projection environments as well as in office meeting spaces, boardrooms, and classrooms where audience attention must stay focused on the projected content.

1 For PT-FRQ50 in QUIET Mode (35 dB in NORMAL/ECO Mode). Operating noise for PT-FRQ60 is 31 dB (QUIET Mode) and 36 dB (NORMAL/ECO Mode). Brightness is reduced when operating the projectors in ECO Mode.

System Daylight View 3

System Daylight View 3 is the premium implementation of Panasonic’s System Daylight View technology. It supports six levels of user-selectable adjustment. To combat the effect of ambient light on the projected image and boost color impact in projection-mapping applications, sharpness, gamma curves, color, and brightness are all optimized to suit on-site conditions.

System Daylight View 3

Multi-Unit Brightness and Color Control

Sensors detect color and brightness apparent on screen. Projectors automatically calibrate for a uniform multi-screen image, adding a layer of convenience and cost saving for long-term deployments.

Multi-Unit Brightness and Color Control

Multi-Screen Support System

Optimally adjusts multiple screens with edge blending, color matching, and digital image enlargement.

Quick Start and Quick Off

Since the laser light-source doesn’t require time to warm up, images appear almost instantly. There’s also no safe cool-down required when disconnecting power—the projector can be turned on and off any time as necessary.

Lamp-based Projector / Laser Projector

Data-Cloning Function

Data-cloning function1 allows various settings and configuration data to be copied from a main projector to up to 99 sub projectors via LAN. This simplifies and expedites the setup process for multi-unit projection applications.

Data-Cloning Function

1 Cloneable data excludes passwords, projector name/ID, and network settings. Data-cloning function is supported among identical projectors only.

Additional Features

  • ・ Supports IPv61
  • ・ Supports 21:9 (2560 x 1080, 3440 x 1440) signal input2
  • ・ Supports Crestron Connected™ V2, Crestron XiO Cloud™2, Art-Net DMX, AMX® DD, and PJLink™
  • ・ DICOM Simulation Mode
  • ・ Free 360° installation
  • ・ Laser safety guaranteed

1 Main firmware version must be 3.00 or higher. Optional AJ-WM50 Series Wireless Module is not compatible with IPv6.

2 Main firmware version must be 3.00 or higher.
