Installation1-Chip DLP™ Projectors

PT-REZ15 SeriesPT-REZ15 / PT-REZ12 / PT-REZ10 / PT-REZ80

Evolved 1-Chip DLP™ Projectors Transform Your Experience with a Frictionless Workflow

PT-REZ15 Series
PT-REZ15/L PT-REZ12/L PT-REZ10/L PT-REZ80/L
15,000 lm1 /
15,500 lm (Center)2
12,000 lm1 /
12,400 lm (Center)2
10,000 lm1 /
10,300 lm (Center)2
8,000 lm1 /
8,200 lm (Center)2
WUXGA (1920 x 1200 pixels)

Note: ET-C1S600 is equivalent to the supplied lens (availability may vary by country or region). Models with an “L” designation ship without a lens.

DLPSOLID SHINE LASER4K DIGITAL LINK3, 44K Accepts Signal4
HDMIINTEL®360°24/7 OparationGeoPro
01 Key Feature

Seamless, High-Contrast Visuals Deepen Engagement

New scene-recognition circuitry and a higher 25,000:15 contrast ratio dramatically improve Dynamic Contrast. Thanks to Rich Color Enhancer, colors are vibrant yet accurate. Refined black-level adjustment enables seamless blending on curved screens, while Gradation Smoother corrects color banding.

More Information

02 Key Feature

Compact and Flexible
for an Efficient Workflow

The compact REZ15 Series delivers full brightness on AC 100–240 V power6 and suits new optional lenses with throw ratios from 0.308:1, ET-FMP50 Series media processors7, and function boards8 for the Intel® SDM standard-compatible SLOT to support AVoIP transmission. Import user test patterns9 and save time with NFC function10 and preactivated Geo Pro11 upgrade kits.

More Information

03 Key Feature

New Compact Body for Maintenance-free Projection

REZ15 Series features an optical engine and laser light source that conform to the IP5X Dust Protected (IEC 60529)12 standard and a refined liquid cooling system, enabling up to 20,000 hours13 of maintenance-free projection. Backup Input14 and Multi Laser Drive Engine enhance reliability and add insurance against interruptions.

More Information

1 Measurement, measuring conditions, and notation method comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped.

2 Average light-output value of all shipped products measured at the center of the screen in NORMAL Mode.

3 Only when the optional TY-SB01DL DIGITAL LINK Terminal Board is loaded.

4 Input signals are converted to the projector’s display resolution upon playback. YPBPR 4:2:0 format only for 4K/60p signals input via DIGITAL LINK.

5 Full On/Full Off with Dynamic Contrast set to [3]. Measurement, measuring conditions, and notation method comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped.

6 Maximum light output may decrease in the following situations: when voltage drops below AC 100 V, when a function board is installed in the slot, when the light source has deteriorated from use, or when dust has accumulated on the optical parts.

7 ET-FMP50 Series media processors are sold separately. For more information, please visit the ET-FMP50 Series webpage.

8 Optional proprietary and third-party function boards are sold separately. Panasonic cannot guarantee the operation of third-party devices.

9 All models support PNG and BMP formats up to 1920 x 1200 pixels. REZ15 also supports JPEG format at the same resolution. For more information, please consult the operating manual.

10 Projectors sold in some countries or regions require an ET-NUK10 Upgrade Kit from PASS to activate the NFC function. See the NFC Regional Compatibility List for details.

11 Visit PASS to register your projector and download free Geometry Manager Pro software (preactivated upgrade kits included).

12 The Dust Protected performance of this unit is not guaranteed to be free from damage or failure under all conditions (environment with conductive dust, etc.). Please use an enclosure in environments with smoke containing oil, salt, and moisture.

13 Around this time, the light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast Contents, NORMAL Mode, Dynamic Contrast [3], temperature 35 °C (95 °F), elevation 700m (2,297 ft) with 0.15 mg/m3 of airborne particulate matter. Panasonic recommends a checkup at the point of purchase after about 20,000 hours. Light-source lifetime may be reduced depending on the environmental conditions. Replacement of parts other than the light source may be required in a shorter period. Estimated maintenance time varies depending on the environment.

14 Primary and backup terminal assignments are fixed. Input signals to primary and backup inputs must be identical.

Introducing the REZ15 Series:
Empowering Epic Experiences

Meet the REQ15 Series

With rising demand for compact 1-Chip DLP™ projectors capable of streamlining workflows and inspiring guests with spectacular visuals, Panasonic has combined its REZ12 Series with the new REZ15 to create the REZ15 Series, our most advanced WUXGA 1-Chip DLP™ projector to date. With a resource-friendly design shaped by co-creative partnerships with industry leaders, the REZ15 Series is ready to reinvent your experience.

Seamless, High-Contrast Visuals Deepen Engagement

Evolved Dynamic Contrast Deepens Immersion

With a higher 25,000:11 contrast ratio, Evolved Dynamic Contrast boasts new scene analysis circuitry that accurately detects light and dark areas, making the difference between black, white, and contrasting colors stand out dramatically.

Evolved Dynamic Contrast

1 Full On/Full Off with Dynamic Contrast set to [3]. Measurement, measuring conditions, and notation method comply with ISO/IEC 21118: 2020 international standards.

Rich Color Enhancer Brings the Creator’s Work to Life

Rich Color Enhancer is an original 2-mode color optimization technology. Dynamic Mode balances brightness and color for clear visibility in bright environments. Standard Mode optimizes color reproduction by expanding red-channel output for vibrant red expression. This is critical for the accurate and immersive reproduction of artwork and other color-rich content.

Rich Color Enhancer Brings the Creator’s Work to Life

Remove Banding with Gradation Smoother

Gradation Smoother reduces banding in shaded color gradients, which can become evident in images lacking sufficient color bit depth. Use the projector remote to select from three correction levels depending on banding severity or disable it when unneeded. Gradation Smoother is a lifesaver when banding is apparent, and there’s no time to re-edit the content.

Remove Banding with Gradation Smoother

Note: Projectors ship with Gradation Smoother set at factory default [2].

Adjust Black Levels on Curved Screens

Panasonic solves the challenge of black-level uniformity in blended areas on curved screens with more flexible adjustment catering to arbitrary screen shapes. Up to 17 control points can be used to reshape black borders for symmetrical fitting without distortion. Black levels can be precisely set within a half-pixel margin for seamless blends, even at close viewing range.

Adjust Black Levels on Curved Screens

Adjust Black Levels Outside the Image Display Area

Evolved black-level adjustment also eliminates black-level bumps appearing in blends outside of the image display area after applying geometric adjustment. By unlinking the black level and geometric adjustment, black-level settings can be applied to the entire blend, including the image overlaps outside the image display area, for a seamless multi-screen image.

Adjust Black Levels Outside the Image Display Area

Note: Black-level area setting must be performed before black-level adjustment. The ability to unlink black-level adjustment from geometric adjustment is supported only on flat screens when adjacent images are aligned vertically or horizontally.

Compact and Flexible for an Efficient Workflow

Delivers Up to 15,000 lm1 Brightness on AC 100–240 V

The REZ15 Series delivers full brightness up to 15,000 lm1 on AC 100–240 V power2, reducing the need to rewire the venue for high-voltage power and saving time, cost, and resources.

1 For the PT-REZ15 only. Please refer to the specifications for the maximum brightness of other models in the series. Measurement, measuring conditions, and notation method all comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped.

2 Maximum light output may decrease in the following situations: when voltage drops below AC 100 V, when a function board is installed in the slot, when the light source has deteriorated from use, or when dust has accumulated on the optical parts.

Light, Compact, and Whisper-Quiet

With a compact body that blends unobtrusively into your spatial design, REZ15 Series projectors save resources and carbon footprint in transport and storage. They can be easily carried and installed with two people, smoothing multi-projection logistics. Furthermore, the high-efficiency liquid cooling system reduces operating noise to as little as 32 dB1, ensuring your audience stays focused on the experience and not the equipment creating it.

1 For the PT-REZ80 in QUIET Mode. Please see the specifications for more information.

Works with an All-New Lens Lineup

REZ15 Series works with new optional motor-driven fixed, zoom, and ultra-short-throw zoom lenses, making it possible to deliver immersive experiences in spaces of any size. The lenses improve native contrast, minimize flare and color blur, and have a wider lens shift range than previous designs. Lens Memory and Auto Lens Identification functions are included, and for the first time, powered periphery focus adjustment1 is now supported via remote control or the Smart Projector Control2 app.

1 Excluding ET-C1S600 and ET-C1T700 lenses.

2 Available free from the App Store or the Google Play store. Check device and OS compatibility before downloading and installing the app.

Note: ET-C1S600 is equivalent to the supplied lens (availability may vary by country or region). Models with an "L" designation ship without a lens. PT-REZ15 Series is compatible with C1 Series lenses only.

Supports New Media Processors to Simplify Multi-Projection

REZ15 Series works with Panasonic’s ET-FMP50 Series media processors to simplify multi-projection complexity. The processors, which comprise box-type and function board-type for the projector's Intel® SDM standard-compatible SLOT, feature automatic warping/blending and media playback capabilities. For more information, please click here.

ET-FMP50

Wide Scalability with Intel® SDM Standard-Compatible SLOT

REZ15 Series works with optional proprietary and third-party function boards that insert into its Intel® SDM standard-compatible SLOT, making it easy to adapt, scale, and expand your projector’s connectivity. For a list of compatible function boards, please click here.

Wide Scalability with Intel® SDM-ready Slot

Note: Terminal layout pictured is for reference only. Optional proprietary and third-party function boards are sold separately. Panasonic cannot guarantee the operation of third-party devices. The transmission method to the slot must be by HDMI™ signal.

Import and Save Custom Test Patterns

Register custom images to a REZ15 Series projector for use as test patterns, start-up logos1, and no-signal screensavers.

Import and Save Custom Test Patterns

1 PT-REZ12/REZ10/REZ80 require logo transfer software.

2 PT-REZ15 supports registering 4x user images in BMP/PNG/JPEG format. PT-REZ12/REZ10/REZ80 support registering 3x user images in BMP/PNG format.

Smart Projector Control App Smooths Your Workflow

Smart Projector Control app1 lets you control up to 64 projectors from your phone or tablet. It enables projector setting adjustment from your device, which is useful when OSD menu projection isn’t possible. In addition to supporting device connection via wireless LAN, which is common to the REZ15 Series, the REZ15 model also exclusively supports a new USB Connect Control2 function. This function enables device connection via USB cable, with the app simulating the projector’s OSD settings menu on the device screen. Other functions include test pattern selection, shutter control, Web Control UI access, lens settings adjustment, brightness locking, and focus adjustment via the device camera3 from distances of up to 30 m
(98 ft)4. The app enables swift connection to the projector via QR Code scanning5, eliminating password/SSID entry. For more, please visit the Smart Projector Control webpage.

Smart Projector Control App

1 Available free from the App Store or the Google Play store. Check device and OS compatibility before downloading and installing the app.

2 Patent pending.

3 Some devices do not support the projector autofocus function.

4 When projecting a 300-inch image. The maximum distance is 3 m (10 ft) for a 100-inch image.

5 Requires optional AJ-WM50 Series Wireless Module (sold separately). Product availability may vary by country or region.

Save Prep Time Before Setup with NFC Function

NFC function1 allows you to prepare your projector for setup at the event site when AC power is unavailable or OSD projection isn’t possible. Just place your phone on the NFC decal to connect, and use the Smart Projector Control2 app to adjust settings such as Projector ID and IP address. Prep for network connection and setup the moment power rolls out on the site, avoiding delays. After the event, projector settings can be reset to factory defaults while unplugged, which used to require OSD menu projection.

NFC Function

1 Projectors sold in some countries or regions require an ET-NUK10 Upgrade Kit from PASS to activate the NFC function. See the NFC Regional Compatibility List for details.

2 Available free from the App Store or the Google Play store. Check device and OS compatibility before downloading and installing the app.

Geo Pro Automates Adjustment and Blending

REZ15 Series offers built-in geometric adjustment tools, including a point-based Free Grid function to correct localized screen distortion. It includes preactivated licenses for upgrade kits with Geo Pro software, comprising the ET-UK20 Geometry Manager Pro Software Upgrade Kit, which expands functionality and adds sophisticated line, shape, and bitmap masking tools, and the ET-CUK10 Auto Screen Adjustment Upgrade Kit, which automates edge-blending including brightness, color, and black level calibration via a camera.

MaskingFunction (Custom Masking)

Note: Visit PASS to register your projector and download free Geometry Manager Pro software for Windows®. Compatible cameras comprise Nikon D5200/D5300/D5500/D5600/D7500. Other conditions apply. Please visit PASS for more information.

Quickly Find the Projection Angle with Angle Monitor

REZ15 Series supports 360° projection angles, enabling image mapping on floors, walls, and 3D objects. However, aligning the projection angle with the design simulation can be challenging and requires two people. The projectors feature a gyro sensor detecting changes in the projector’s pitch and roll angles, graphically displayed in the OSD settings menu. Installers can adjust the projection angle without needing assistance.

Quickly Find the Projection Angle with Angle Monitor

Note: The displayed values are based on the results of angle sensor detection and may differ from the actual projection angle. They are for reference only, and accuracy is not guaranteed.

New Screen Marker Function

The REZ15 adds a screen marker function that simplifies adjustments and measurements. The Line Frame tool supports adjustable V/H margin lines that enable projector pre-adjustment before peripheral equipment is set up and a crosshair marker for fixed-point measurement.

Updated Web Control Interface

The REZ15 features an updated Web Control UI supporting dark and light modes. Information within the UI is reorganized for improved visibility. You can set projector command schedules such as power on/off, view the projector’s OSD settings menu on screen, and customize device status info on the Home screen. Other updates include adaptive screen sizes and enhanced mobile versions, empowering efficient management.

Note: PT-REZ12/REZ10/REZ80 supports the previous Web Control version only.

GUI

New Compact Body for Maintenance-free Projection

Dust-Resistant Optical Engine and Liquid Cooling System

REZ15 Series’s optical engine and laser light source conform to the IP5X Dust Protected (IEC 60529)1 standard. This eliminates the need for a filter and enables 20,000 hours2 of maintenance-free projection. Reliability is proven by accelerated dust-chamber testing in significantly dustier conditions than those in which some competitive products are tested.

Hermetic Optical Engine and Liquid Cooling System
Hermetic Optical Engine and Liquid Cooling System

1 The Dust Protected performance of this unit is not guaranteed to be free from damage or failure under all conditions (environment with conductive dust, etc.). Please use an enclosure in environments with smoke containing oil, salt, and moisture.

2 Around this time, the light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast Contents, NORMAL Mode, Dynamic Contrast [3], temperature 35 °C (95 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of airborne particulate matter. Panasonic recommends a checkup at the point of purchase after about 20,000 hours. Light-source lifetime may be reduced depending on the environmental conditions. Replacement of parts other than the light source may be required in a shorter period. Estimated maintenance time varies depending on the environment.

Backup Input Redundancy

Two identical signals can be simultaneously transmitted to HDMI 1 (Primary) and HDMI 2 (Backup). If transmission to the primary input is interrupted, the projector switches to the backup automatically in a minimum of 0.3 seconds1 without screen-blanking. This layer of insurance gives greater peace of mind during events where image display can’t be interrupted.

Backup Input Redundancy

1 Varies depending on the Backup Input mode and the connected external device.

Note: Primary and backup terminal assignments are fixed. The input signals to primary and backup inputs must be identical.

Multi-Laser Drive Engine Enhances Reliability

Multiple laser modules are equipped with Failover Circuitry. In the unlikely event a single diode fails, Failover Circuitry continues to supply electricity to the functional diodes in the series, minimizing brightness loss. If the same issue were to occur in projectors without Failover Circuitry, all diodes in the module might shut down, resulting in a significant loss of brightness.

Highly Reliable Multi-Laser Drive Engine

Reduce Errors with Remote Preview LITE

Remote Preview LITE allows projectionists to confirm connectivity and assess image adjustments before the video is projected by viewing preview thumbnails on a laptop. This is valuable at live events where checking content on the screen is limited due to soundchecks or sunlight. Accessible via software or web browser, it works with the projector in Standby1 or with the shutter on, minimizing errors before performances.

Remote Preview LITE for Monitoring During Events

1 Projector must be set to Pre-Show Mode.

Note: Requires Multi-Monitoring & Control Software Version 3.3 or later available free here. For more information, click here.

Other Features

  • ・ Supports Art-Net DMX, PJLink™, Crestron Connected® V2,
    Crestron® XiO Cloud, and Extron XTP®
  • ・ Supports IPv61 network protocol
  • ・ 1 USB port for DC 5 V/2 A power supply, 1 USB port for optional AJ-WM50
    Series Wireless Module and data transfer from USB memory devices
  • ・ Compatible with the Multiple PJ Firmware Batch Update Tool
  • ・ Contrast Sync and Shutter Sync Functions
  • ・ Data-Cloning Function via LAN or USB2
  • ・ Supports widescreen 21:9 input signals
  • ・ Quick Start and Quick Off
  • ・ Multi-screen Support System
  • ・ Multi-Unit Brightness and Color Control
  • ・ DICOM Simulation Mode
  • ・ Waveform Monitor Function

1 Optional AJ-WM50 Series Wireless Module is not compatible with IPv6.

2 Data-cloning is supported among models in the same series with the same resolution. Excludes passwords, projector ID, and network settings.
